COOLERMASTER 460W ELITE SERIES ATX POWER SUPPLY -USED - TESTED

The Elite 460 RS-460-PSAR-J3 from Cooler Master pushes out 460W of power to handle your system's thirst for juice. It is compliant with the newest Intel ATX 12V v2.31 specifications so it is a great choice for both replacements and new builds.

There are plenty of connectors for all your system add-ons including 3 peripheral and 4 SATA. This power supply also provides a PCIe connector for your advanced video card. The +12V output duties are divided between two 18A rails for plenty of balanced power. Featuring a 120mm fan with built-in EMI and noise filter, the Cooler Master Elite 460 RS-460-PSAR-J3 is a quiet and cool power supply.

Specifications
Model
Brand COOLER MASTER
Model RS-460-PSAR-J3
Series Elite 460

Spec
Type ATX12V V2.31
Maximum Power 460W
Fans 120mm fan
Main Connector 20+4Pin
+12V Rails 2
PCI-Express Connector 1 x 6-Pin
SATA Power Connector 4
SLI No
CrossFire No
Power Good Signal 100-500ms
Hold-up Time 17ms min.
Efficiency > 70%
Over Voltage Protection Yes
Input Voltage 110 - 120 V/ 220 - 240 V
Input Frequency Range 47 - 63 Hz
Input Current 8.5A @ 115V, 5A @ 220V
Output +3.3V@20A,+5V@20A,+12V1@18A, +12V2@18A,-12V@0.8A,5VSB@2.5A
MTBF >100,000 Hours
Approvals CE, GOST, C-tick

Features
Connectors 1 x Main connector (20+4Pin) 1 x 12V(8Pin) 3 x peripheral 4 x SATA 1 x Floppy 1 x PCI-e
Features Compliance with the newest Intel standard ATX 12V V2.3 More than 70% efficiency at typical load operation High Performance components design for better reliability Green power design to meet energy star and blue angel requirements Multiple protection design(OVP/OCP/OPP/SCP) Support dual +12V1 and +12V2 outputs for higher power usage One 4+4 pin +12V CPU connector for high-end CPU EMI & Noise filter built in design

Manufacturer Warranty 1 year
