Specifications
Processor Intel® Core i7-14700K Processor
Number of Cores 20 (8P + 12E)
Number of Threads 28
Base Clock Speed P-core: 3.40 GHz
E-core: 2.50 GHz
Max Turbo Frequency 5.60 GHz
Intel® Thermal Velocity Boost Frequency N/A
Intel® Turbo Boost Max Technology 3.0 Frequency 5.60 GHz
Performance-core Max Turbo Frequency 5.50 GHz
Efficient-core Max Turbo Frequency 4.30 GHz
Cache 33 MB Intel® Smart Cache
Total L2 Cache 28 MB
Unlocked Yes

Memory
Memory Type DDR5-5600
DDR4-3200
Memory Channels 2
Max Memory Bandwidth 89.6 GB/s
ECC Memory Support Yes

Graphics
Processor Graphics Intel® UHD Graphics 770
Graphics Base Frequency 300 GHz
Graphics Max Dynamic Frequency 1.6 GHz
Execution Units 32
Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
Max Resolution HDMI: 4096 x 2160 @ 60Hz
DP: 7680 x 4320 @ 60Hz
eDP - Integrated Flat Panel: 5120 x 3200 @ 120Hz
DirectX Support 12
OpenGL Support 4.5
OpenCL Support 3.0
Multi-Format Codec Engines 2
Intel® Quick Sync Video Yes
Intel® Clear Video HD Technology Yes
# of Displays Supported 4

Expansion Options
Direct Media Interface (DMI) Revision 4.0
Max # of DMI Lanes 8
Scalability 1S Only
PCI Express Revision 5.0 / 4.0
PCI Express Configurations Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes 20 Total (16 PCIe 5.0 + 4 PCIe 4.0)

Advanced Technologies
Intel® Gaussian and Neural Accelerator (GNA) 3.0
Intel® Thread Director Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Speed Shift Technology Yes
Intel® Thermal Velocity Boost No
Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Technology 2.0
Intel® Hyper-Threading Technology Yes
Intel® 64 Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Volume Management Device (VMD) Yes

Security & Reliability
Intel® Standard Manageability (ISM) Yes
Intel® Control-Flow Enforcement Technology Yes
Intel® AES New Instructions Yes
Intel® Secure Key Yes
Intel® OS Guard Yes
Execute Disable Bit Yes
Intel® Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel® Stable IT Platform Program (SIPP) Yes
Intel® vPro Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes

Packaging
Thermal Solution None (Sold Separately)
Processor Base Power 125 W
Maximum Turbo Power 253 W
Architecture Intel 7 (10nm Enhanced SuperFin)
Socket Socket LGA 1700
